| Distribution boom type |
B5RZ 53/48 |
| Max. Vertical reach |
52.1 m |
| Max horizontal reach |
48.1 m |
| Mast elements / folding |
5 / RZ |
| CARBON SECTIONS |
4 and 5 |
| Pipelines |
125 mm double-walled |
| Min. Unfolding height |
13.9 m |
| Swivel range |
+/- 270 ° |
| Pump unit type |
HP 1808 ECX |
| Max. Delivery rate |
180 m³ / h |
| Max. Concrete pressure |
83 bar |
| Max. Strokes / min. |
27 |
| Delivery cylinder |
260 x 2,100 mm |
| S-pipe size |
10 inches |
| Hydraulic circuit |
closed |
| Tax system |
electronically |
