| Distribution boom type |
B7HRR 80/76 |
| Max. Vertical reach |
79.5 m |
| Max horizontal reach |
74.5 m |
| Mast elements / folding |
7 / RR |
| CARBON SECTIONS |
4, 5, 6 and 7 |
| Pipelines |
125 mm double-walled |
| Min. Unfolding height |
15.66 m |
| Swivel range |
+/- 270 ° |
| Pump unit type |
HP 1808 ECX |
| Max. Delivery rate |
180 m³ / h |
| Max. Concrete pressure |
83 bar |
| Max. Strokes / min. |
27 |
| Delivery cylinder |
260 x 2,100 mm |
| S-pipe size |
10 inches |
| Hydraulic circuit |
closed |
| Tax system |
electronically |
