Description
Lae alla PDF
| Distribution boom type |
B4Z 38/34 |
| Max. Vertical reach |
37.6 m |
| Max horizontal reach |
33.4 m |
| Mast elements / folding |
4 / Z |
| Pipelines |
125 mm double-walled |
| Min. Unfolding height |
9.1 m |
| Swivel range |
+/- 270 ° |
| Pump unit type |
HP 1608 EC |
HP 1606 H. |
| Max. Delivery rate |
160 m³ / h |
160 m³ / h |
| Max. Concrete pressure |
80 bar |
53 bar |
| Max. Strokes / min. |
31 |
30th |
| Delivery cylinder |
230 x 2,100 mm |
230 x 2,100 mm |
| S-pipe size |
9 inches |
9 inches |
| Hydraulic circuit |
closed |
open |
| Tax system |
electronically |
hydraulically |
