| Distribution boom type |
B5RZ 56/51 |
| Max. Vertical reach |
55.1 m |
| Max horizontal reach |
49.9 m |
| Mast elements / folding |
5 / RZ |
| Pipelines |
125 mm double-walled |
| Min. Unfolding height |
14.4 m |
| Swivel range |
+/- 270 ° |
| Pump unit type |
HP1608EC |
HP1606H |
HP1808ECX |
| Max. Delivery rate |
160 m³ / h |
160 m³ / h |
180 m³ / h |
| Max. Concrete pressure |
80 bar |
53 bar |
83 bar |
| Max. Strokes / min. |
31 |
30th |
27 |
| Delivery cylinder mm |
230 x 2,100 |
230 x 2,100 |
260 x 2,100 |
| S-pipe size |
9 inches |
9 inches |
10 inches |
| Hydraulic circuit |
closed |
open |
closed |
| Tax system |
electronically |
hydraulically |
electronically |
