| Distribution boom type |
B5RZ 40/35 |
| Max. Vertical reach |
39.1 m |
| Max horizontal reach |
34.5 m |
| Mast elements / folding |
5 / RZ |
| CARBON SECTIONS |
4 and 5 |
| Pipelines |
125 mm double-walled |
| Min. Unfolding height |
8.6 m |
| Swivel range |
+/- 270 ° |
| Pump unit type |
HP 1608 EC |
| Max. Delivery rate |
160 m³ / h |
| Max. Concrete pressure |
80 bar |
| Max. Strokes / min. |
31 |
| Delivery cylinder |
230 x 2,100 mm |
| S-pipe size |
9 inches |
| Hydraulic circuit |
closed |
| Tax system |
electronically |
