| Distribution boom type |
B4ZR 24/20 |
| Max. Vertical reach |
23.59 m |
| Max horizontal reach |
19.9 m |
| Mast elements / folding |
4 / ZR |
| Pipelines |
125 mm double-walled |
| Min. Unfolding height |
4.96 m |
| Swivel range |
+/- 270 ° |
| Pump unit type |
HP 907 H. |
HP 1608 EC |
| Max. Delivery rate |
90 m³ / h |
160 m³ / h |
| Max. Concrete pressure |
70 bar |
80 bar |
| Max. Strokes / min. |
29 |
31 |
| Delivery cylinder |
200 x 1,650 mm |
230 x 2,100 mm |
| S-pipe size |
8 inches |
9 inches |
| Hydraulic circuit |
open |
closed |
| Tax system |
hydraulically |
electronically |
