Distribution boom type | B5Z 36/31 |
---|---|
Max. Vertical reach | 35.1 m |
Max horizontal reach | 31.1 m |
Mast elements / folding | 5 / Z (endless rotation of arm 5!) |
Pipelines | 125 mm double-walled |
Min. Unfolding height | 7.03 m |
Swivel range | +/- 270 ° |
Pump unit type | HP 1608 EC | HP 1606 H. |
---|---|---|
Max. Delivery rate | 160 m³ / h | 160 m³ / h |
Max. Concrete pressure | 80 bar | 53 bar |
Max. Strokes / min. | 31 | 30th |
Delivery cylinder | 230 x 2,100 mm | 230 x 2,100 mm |
S-pipe size | 9 inches | 9 inches |
Hydraulic circuit | closed | open |
Tax system | electronically | hydraulically |
