Kirjeldus
Lae alla PDF
| Distribution boom type |
B5RZ 61/56 |
| Max. Vertical reach |
60.1 m |
| Max horizontal reach |
55.1 m |
| Mast elements / folding |
5 / RZ |
| Pipelines |
125 mm double-walled |
| Min. Unfolding height |
13.8 m |
| Swivel range |
+/- 270 ° |
| Pump unit type |
HP 1808 ECX |
HP 1606 H. |
| Max. Delivery rate |
180 m³ / h |
160 m³ / h |
| Max. Concrete pressure |
83 bar |
53 bar |
| Max. Strokes / min. |
27 |
30th |
| Delivery cylinder |
260 x 2,100 mm |
230 x 2,100 mm |
| S-pipe size |
10 inches |
9 inches |
| Hydraulic circuit |
closed |
open |
| Tax system |
electronically |
hydraulically |
Arvustused
Tooteülevaateid veel ei ole.
